CH-U360RX

CH-U360RX EOL

UHD HDMI to IP AV over IP Point-to-Point Receiver with USB / KVM Extension

HDCP 1.4 & 2.2 compliant
Support USB 2.0 high-speed devices
Operate with USB 2.0 high speed host controllers
The Mic In on a connected Receiver will send audio directly to the analog Line Out on Transmitter.
Supports resolutions up to 3840 x 2160 RGB, DVI supports compatible to 2560 x 1440.
Simultaneous transmission of video, audio, data over a single Cat.5e/6/7 cable up to 100m (328ft).
Supports IR and RS-232 bypass.

The Single over IP solution is designed to control and switch between KVM, PCs/laptops and monitors to any connected devices to controlled single monitor cross-transmit with KVM. It is point-to-point application by setting identical channel number with dip-switch for both Transmitter and Receiver. It is a cost effective ideal solution for monitoring or displaying multiple sources simultaneously for use in control rooms, conference rooms, classrooms or gaming usage. This KVM Extender allows you to control your PC using a keyboard, mouse and monitor with a maximum resolution of 4K or 2K at distances of up to 100musing one Cat.6 cables. The USB functionality allows the system to act like a remote USB hub which provides a flexible remote KVM platform. Basic USB keyboard, mouse functions are supported. It is compatible with USB 2.0 devices with high power demands, storage or hubs. USB touch screens or other advanced interface devices/HIDs are supported also. It is isochronous equipped to achieve web cam real-time transmission. It supports 4K, audio and HDCP. Analogue stereo audio, IR and RS-232 signal bypass are also supported

Interfaces
Input Port	1 Analog Stereo (3.5mm) 1 GbE LAN (RJ-45)
Output Port	1 HDMI 1 Analog Stereo (3.5mm)
Control I/O	1 IR Extender (3.5mm) 1 RS-232 (3.5mm) 7 USB (Type-A)

Video
HDMI Compliance	HDMI 1.4
HDCP Compliance	2.2
Output Signal Type	3840 x 2160 RGB

Resolutions
Maximum Output	HDMI	3840 x 2160 RGB

Audio
HDMI	LPCM (8 Channels), Bitstream, High Bit Rate Bitstream
Mic In	TBD
Line Out	TBD

Power
Power Supply	12V/3A DC (Locking))
Power Consumption	30W

Enclosure
Chassis Material	Metal (Steel)
Chassis Color	Black
Dimensions (W×H×D)	180mm×103mm×25mm [Case Only] 180mm×111.6mm×25mm [All Inclusive]
Weight	368g

Field Firmware Update
WebGUI

Ordering Information
Model No.	Product Description
CH-U360RX	UHD HDMI to IP AV over IP Point-to-Point Transmitter with USB / KVM Extension
CH-U360TX	UHD HDMI to IP AV over IP Point-to-Point Transmitter with USB / KVM
