CMX-112 EOL
HD/SD Digital AV Mixer
- Selective size and position for digital effects area and PIP windows.
- Automatic fade and wipe with speed preset control.
- Digital effects-Still, Mosaic, Paint, Negative.
- 96 wipe patterns.
- Chroma key & Luminance key.
- High Picture Quality.
- 3x8 back color.
- Joystick control for digital effect position.
- Fade control for Video and Audio.
- Video and Audio mixing.
- Two HDMI source inputs.
- Two Component source inputs.
- Two Composite and S-Video source inputs.
- One HDMI recording output.
- Two Component recording outputs
- One Composite and S-Video recording outputs.
- One Composite and S-Video preview outputs (OSD).
- Auxiliary audio input.
- Microphone input and headphone output.
- Picture and Picture control. (3 window sizes)
- Each A/B BUS can adjust the Contrast/ Brightness/ Color/ HUE/ Detail & Aspect Ratio.
- Supports Lip-Sync delay up to 170ms.
- Composite supports 3D comb filter and YC separation.
- Motion and Edge Adaptive De-interlacing.
Note: When receiving content that has HDCP encryption there will be no video output, the
image will show with Blue screen.
