CPLUS-VHHE EOL
Replacement Model >CPLUS-V2T
4K UHD+ EDID Emulator with HDCP Converter
- HDMI input and output with 18Gbps (600MHz) 4K UHD support
- DVI 1.0 compliant with the use of an HDMI-DVI adapter
- HDCP 1.4 and 2.2 compliant
- Supports HD resolutions up to 3840×2160@60Hz (4:4:4, 8-bit) & 4096×2160@60Hz (4:4:4, 8-bit)
- Supports pass-through of LPCM 2.0/5.1/7.1, Bitstream, and HD Bitstream audio formats
- Video source signal and display EDID analysis
- HDCP 2.2 to 1.4 conversion
- EDID selectable between internal, external and user’s custom EDID
- PC-based EDID management tool support
- LED display with easy viewing of the current signal status
- Supports 18Gbps bandwidth bypass and 18Gbps color subsampling to 10.2Gbps (4K@50/60Hz, 4:4:4 to 4K@50/60Hz, YUV 4:2:0)
- Supports firmware updates via USB
