CED-2M
UHD+ EDID Manager
- HDMI input and output with 18Gbps (600MHz) 4K UHD support
- DVI 1.0 compliant with the use of an HDMI-DVI adaptor
- Supports HD resolutions up to 3840×2160@60Hz (4:4:4, 8-bit) & 4096×2160@60Hz (4:4:4, 8-bit)
- Supports 48-bit Deep Color up to 1080p@60Hz
- Supports pass-through of LPCM 2.0/5.1/7.1, Bitstream, and HD Bitstream audio formats
- Supports CEC pass-through
- Supports four distinct EDID functions: Read and copy the connected display’s EDID into the unit
- Write: Overwrite connected display’s EDID (only available on displays which explicitly support the overwrite function)
- Emulation: The HDMI input device reads the EDID stored within the unit (built-in, learned, or created)
- Bypass: The HDMI input device reads the EDID directly from the connected display - 8 built-in standard EDIDs, 8 slots for user-created or learned EDIDs, and EDID bypass support
- PC-based EDID management tool support
