CAC-TXA
HDMI over 5 Coaxial Transmitter
- Compatible with HDMI and DVI 1.1
- Improved color gamut (i.e. 'Deep Color'/xvYCC).
- High Definition audio (8-channel audio support).
- Supports High Resolutions from VGA (640×480) to WUXGA (1920×1200).
- Supports HDTV resolutions from 480i~1080p/12-bit.
- Built in Consumer Electronics Control (CEC).
- Supports 'Deep Color'
- Gigabit digital transport needs:
- HDMI 1.3 (Category)/DVI (10.2Gb/s). The RG6 type 75Ω coaxial cables can operate up to 100m at 10.8Gb/s.- The receiver can be powered either from the supplied AC power adaptor or by the Transmitter unit over cable.
Note: running off the Transmitter may result in a loss of performance over longer cable distances
- Supports VESA DDC, CEC, Hot Plug Detect (HPD) and xvYCC. - Easy to install and operate
