CH-1610RXPL
UHD HDMI/USB to HDBaseT Receiver
- Supports pass-through of audio formats including LPCM 2.0/5.1/7.1, Bitstream and HD Bitstream over HDMI
- HDBaseT 2.0 compatible
- HDMI 2.0 and DVI 1.0 compatible
- HDCP 2.2 and HDCP 1.x compliant
- Simultaneous transmission of uncompressed data over a single CAT5e/6/7 cable up to 35m
- Supports UHD resolutions up to 3840×2160@60Hz (4:2:0, 8-bit) & 4096×2160@60Hz (4:2:0, 8-bit)
- Supports 16-bit Deep Color up to 1080p@60Hz
- Supports standard 48V from Transmitter (PSE) to Receiver (PD)
PRODUCTS FEATURED
CH-1610TXPL
UHD HDMI/USB to HDBaseT Transmitter
The HDMI over single CAT5e/6/7 Transmitter set can send uncompressed audio/video over a single run of CAT5e/6/7 cable at a distance up to 35 meter. Multi-control interfaces are available which includes IR, RS-232 and USB connection. This extender complies with advanced protocols of HDCP2.2 and HDMI 2.0, as well as supporting the legacy HDCP 1.x standards.
