CLUX-SDI2DVIA
SDI to DVI VIDEO FORMAT CONVERTER
• Supports the SD-SDI (SMPTE 259M-C), HD-SDI (SMPTE 292M), and 3G-SDI (SMPTE 424M/425M-A) standards
• Supports standard SDI input resolutions including: 480i@59.94Hz, 576i@50Hz, 720p@50/59.94/60Hz, 1080i@50/59.94/60Hz, 1080p@23.98/24/25/29.97/30/ 50/59.94/60Hz
• Performs unscaled format conversion from SDI to HDMI/DVI (format selected based on connected sink type) with output resolutions up to 1080p@60Hz
• Up to 8 channels of extracted LPCM audio is supported when outputting HDMI
• Analog line-level audio output signal is extracted from the first audio channel pair of the SDI source
