CPLUS-44PLV
UHD+ 4x4 HDMI over HDBaseT Matrix with AVLC
- HDMI with HDR & 4K@60Hz support, DVI 1.0 compatible
- Routes four HDMI sources to four displays using four HDBaseT outputs
- Supports deep color input and output up to 12-bit
- Supports 10-bit and 12-bit HDR (High Dynamic Range) bypass (Output requires AVLC receiver)
- Supports automatic conversion of 4K@50/60Hz (4:4:4) sources to 4K@50/60Hz (4:2:0) or 1080p50/60 for non-AVLC HDBaseT receivers or if a connected display can’t support the original resolution. Note: 1080p conversion is only available on outputs A & C.
- Supported HDBaseT feature set: HD Video & Audio, PoH (PSE), and Control (Bidirectional IR pass through)
- 4K signals can be transmitted up to 35m via Cat.5e/6 and up to 40m via Cat.6a/7
- Supports pass-through of these standard digital audio formats via HDBaseT: LPCM (up to 8 channels), Bitstream, and HD Bitstream
- High quality Digital to Analog Conversion (DAC) of LPCM 2.0 audio sources for local audio breakout.
- Supports generation of OSD banner information
- Advanced internal and external EDID management with 4 sets of configurable EDID settings
- 1U rack mounted design
- Control via front panel controls, Ethernet (Telnet & WebGUI), RS 232, & IR remote
