CPLUS-1082VA
UHD + 10×10 HDMI/HDBaseT Matrix with AVLC & Audio Matrixing
- Routes ten HDMI sources to ten displays using eight HDBaseT outputs and two independent or mirrored HDMI outputs
- Supports Deep Color input and output up to 12-bit
- Supports 10-bit and 12-bit HDR bypass
- Supported HDBaseT feature set: HD Video & Audio, 100BaseT Ethernet, 48V PoH, and Control (Bidirectional IR/RS-232 pass through)
- All HDBaseT outputs support OAR (Optical Audio Return)
- 4K signals can be transmitted up to 70m via Cat.5e/6 and up to 100m via Cat.6a/7
- Supports pass-through of these standard digital audio formats via HDMI/HDBaseT: LPCM 2.0/5.1/7.1, Bitstream, and HD Bitstream
- Advanced DAC (Digital to Analog Conversion) and ADC (Analog to Digital Conversion) for audio integration
- Supports integrated audio over CAT inputs and outputs for transmission up to 300m
- Supports volume, treble, bass, and audio delay for lip-sync (up to 230ms) on analog audio outputs and mute on all outputs
- Audio mixer functionality (three mixers in total)
- Advanced internal and external EDID management with 4 sets of configurable EDID settings
- Internal test pattern generation (up to 1080p) for self and sink testing
- 2U rack mounted design
- Control via front panel buttons with OLED menu, Ethernet (Telnet & WebGUI), RS-232, and IR remote
