Scaler

CPLUS-V4H2HUSB

4K@60 4x2 Seamless Matrix with USB Docking

  • 2 HDMI inputs, 2 USB(Type-C) inputs and 2 HDMI outputs up to 4K@60 4:4:4
  • Controllable via front panel buttons, Telnet, RS-232, and OSD via USB mouse
  • 2 USB Type-C Inputs support USB3.1 Gen1 to Ethernet and DP video.
  • Two USB Type-C ports respectively provide 45W and 30W of power to each connected device
  • Supports PiP (Picture-in-Picture), PoP, quad mode display options with independent audio source selection or auto audio switch by following USB control function.
  • Seamless switching (no loss of sync to display) when switching sources in both matrix and multi-view modes.
  • Supports easy adjustment of window size, position and settings in the PiP windowing mode via mouse.
  • Supports the ability to store a multi-window arrangement as a preset that can be recalled later
  • Selected window will have a border to highlight the window that is being operated.
  • DVI 1.0 compatible with the use of an HDMI-DVI adaptor
  • HDCP 1.x and 2.2 compliant
