CPRO-2E4KS

CPRO-2E4KS EOL

HDMI 4K2K Scaler

Supports HDMI signal upscale to 4K2K or downscale to 1080p@24
Supports HDMI signal bypass
Simultaneous HDMI outputs
Friendly and simple to use

The HDMI 4K2K Scaler is designed to upscale 1080p@24 signal into 4K2K or downscale 4K2K signal into 1080p@24. With friendly and simple design which allows user with direct viewing on input resolution and switching output signal format up to 2 simultaneous HDMI. The HDMI 4K2K Scaler is your best media between HD and Ultra HD signal.

Video Frequency	300MHz/9Gbps
Input Port	1 x HDMI
Output Ports	2 x HDMI
4K2K HDMI Cable Distance	In 5M, Out 10M
Power Supply	5V / 2.6A DC (US/EU standards, CE/ FCC/UL certified)
ESD Protection	Human body model: ±8kV (air-gap discharge) ±4kV (contact discharge)
Dimensions (mm)	102(W) x 102(D) x 25 (H) 102(W) x 108.75(D) x 25 (H)/Including Jacks
Weight(g)	220
Chassis Material	Aluminum
Silkscreen Color	Black
Operating Temperature	0˚C~40˚C / 32˚F ~ 104˚F
Storage temperature	-20˚C~60˚C / -4˚F ~ 140˚F
Relative Humidity	20~90% RH (no condensation)
Power Consumption (W)	2.4W

Product Support
Upload Date	File Name	Version	OS	Description	Download
2021/07/12	CPRO-2E4KS Manual	1	all	CPRO-2E4KS Manual
