Scaler

CSC-VPR-3420

Multi-View with Streaming Solution for Video Conference

Multi-view Switch

  • HDMI inputs and outputs with 18Gbps (600MHz) 4K UHD support
  • Seamless switching (no loss of sync to display) when switching sources in 4x2 matrix mode.
  • Supports the ability to store a multi-window arrangement as a preset that can be recalled later
  • EDID management
  • Supports easy adjustment of window size, position and settings in the PiP windowing mode via the WebGUI
  • Controllable via front panel buttons, WebGUI, Telnet and RS-232

Video Capture portion

  • Automatically scales 4K sources to 1080p for USB capture
  • Supports video timing stabilization to help ensure a reliable and stable USB capture stream
  • Capturing over USB 3.0 allows uncompressed video and audio data capture (1080p, LPCM 2.0)
  • Capturing over USB 2.0 applies minimal MJPEG compression to the video and audio data (1080p, LPCM 2.0)
  • Supports capturing 2 channel digital audio from either HDMI (LPCM 2.0) or the 3.5mm analog audio input (selectable via capture software)
  • Compliance with the UAC (USB Audio Class) and UVC (USB Video Class) standards, allows the unit to support most common capture and video streaming softwares
