CDP-14C
1 by 4 Display Port Splitter
- Supports DisplayPort specification V1.1a
- Deep color video up to 12bit, resolution support up to 2560 x 1600
- Supports audio up to PCM 7.1(32-192kHz Fs sample rate)
- Supports pixel component formate with RGB; YCbCr 422; YCbCr 444
- Color sapce conversion between RGB and YCbCr color space
- Supports 1.62/2.7 Gbps data rate (Low/High bit rate)
- Supports flexible 1/2/4 lanes configurations; Full 10.8Gbps data ratesupport (4lanes at 2.7Gbps)
- Supports EDID switch and setting Note: This device supports only DisplayPort mode, it cannot connect DP to HDMI level shift convert.
